Rockford Fosgate Punch P2 6"x9" 2-Way Convertible Speakers (P2V269)

Rockford Fosgate Punch P2 6"x9" 2-Way Convertible Speakers (P2V269)

The Punch P2 6"x9" is a 4Ω convertible speaker you can fit as a coaxial or split into a component setup. It’s made for the oval 6"x9" locations in rear decks and doors, and it comes with the tweeter cups, crossovers and wiring for either install.

Key features:

• Convertible: leave the tweeter on the woofer for a coaxial install, or lock it into a mounting cup and place it higher in the door, dash or pillar
• Interchangeable Locking Mechanism (I.L.M.) lets you lock and unlock the tweeter from the wired mounting cup. A removal tool is included
• 3/4" inverted dome tweeter with a 9kHz high-pass crossover for clear, controlled highs
• VAST 2.0™ cone technology gives 25% more cone area for deeper bass and stronger output
• 75W RMS / 150W peak power handling at 4Ω, with frequency response from 45Hz to 25kHz
• 90dB sensitivity (1W/1M), so it makes good use of modest amplifier power
• Reinforced polymer basket, Santoprene™ surround and Nomex® spider built to handle sustained output
• Removable motor cover reduces the mounting depth from 3.13" to 2.55" when space is tight
• External crossover has a 0dB or -3dB tweeter attenuation setting, so you can adjust the highs to suit your cabin

Who it’s for:
Owners and installers replacing factory or older aftermarket 6"x9" speakers who want a better driver and the choice of coaxial or component. It also suits installs where the final tweeter position isn’t clear until the trim is off.

Fitment & installation notes:

• Cutout size: 8.41" x 5.71" (213.5mm x 145mm)
• Mounting depth with motor cover: 3.13" (79.4mm)
• Minimum mounting depth with motor cover removed: 2.55" (64.7mm)
• Front side clearance: 0.42" (10.6mm)
• Flush-mount and surface-mount tweeter cups both included
• Four 18" crossover wiring extensions included so the crossovers can be mounted away from the speaker
• Check your existing speaker size and cutout before ordering
• No grille or trim ring included, so check whether your install location needs one
• Cutout template included for marking the mounting hole

Specifications:

• Nominal impedance: 4Ω
• Power handling: 75W RMS / 150W peak
• Frequency response: 45Hz–25kHz
• Sensitivity: 90dB (1W/1M) / 93dB (2.83V/1M)
• Voice coil diameter: 1.25" (32.5mm)
• Tweeter crossover, internal: high-pass at 9kHz, 6dB/octave
• Tweeter crossover, external: high-pass at 9kHz, 12dB/octave, with 0dB or -3dB attenuation
• Fs: 60Hz

In the box & warranty:

• 2 x 6"x9" 4Ω speakers and 2 x 3/4" 4Ω tweeters
• 2 x tweeter passive crossover networks
• 2 x flush-mount tweeter cups and 2 x surface-mount tweeter cups
• 2 x woofer phase plugs
• Tweeter removal tool
• Cutout template
• Mounting screws: 8 x #8 x 32mm (speaker), 4 x #4 x 16mm (tweeter), 4 x #8 x 20mm (crossover)
• 4 x 18" crossover wiring extensions and 2 x 18 AWG red/black speaker wire (205mm)
• 18 AWG female crimp spade connectors (3 x negative .187", 3 x positive .250"), 4 x crimp butt connectors and 6 x zip ties
